KTS-650 is a ranging-type long-tube thermal infrared imaging scope, a tactical-grade optical system for extreme combat environments, serving as the ultimate solution for special operations, border patrols, and professional hunting.
2200m laser ranging (±0.3m@1000m), military VOx detector (dual-resolution), 1024×768 AMOLED display.
3s rapid deployment via 30mm tube & quick-release base, -40℃ to +60℃ operation, IP67 protection, 10-hour battery life.
![]() | ![]() | ![]() | ![]() |
KTS-650 is a ranging-type long-tube thermal infrared imaging scope, a tactical-grade optical system for extreme combat environments, serving as the ultimate solution for special operations, border patrols, and professional hunting.
2200m laser ranging (±0.3m@1000m), military VOx detector (dual-resolution), 1024×768 AMOLED display.
3s rapid deployment via 30mm tube & quick-release base, -40℃ to +60℃ operation, IP67 protection, 10-hour battery life.
![]() | ![]() | ![]() | ![]() |
| Sensor | Type | VOX Uncooled Sensor, 8-14μm |
| Resolution | 640×512@12μm | |
| Noise Equivalent Temperature Difference (NETD) | <20mK(@25°C,F#1.0,25Hz) | |
| Frame Rate | 50Hz | |
| Lens | Objective Focal Length | 35mm/F1.0 | 50mm/F1.0 |
| Field of View (±0.3°) | 12.5°×10° | 8.7°×7° | |
| Magnification | 1.61×-12.88× | 2.31×-18.48× | |
| Exit Pupil Distance | 60mm | |
| Diopter Adjustment | -5~+5 | |
| Detection Distance (m) | 1800 | 2600 | |
| Display | Type | 0.39-inch OLED |
| Resolution | 1024×768 | |
| Hardware | Laser Rangefinder | 5-2200m, Ranging Accuracy ±1m |
| WiFi | Built-in WiFi | |
| Interface | USB-C | |
| Tube Diameter | 30mm | |
| Other Functions | Microphone, Bluetooth | |
| System | Recording Function | Photo/Video (Audio Recording Supported) |
| Storage Capacity | 32GB | |
| Power Supply | Battery Type | Built-in Dual 18650 Batteries (CR123 Compatible) |
| Continuous Working Time | 10 Hours | |
| Environmental Adaptability | Operating Temperature | -20°C~+50°C |
| Shock Resistance | 1000g | |
| Protection Class | IP67 | |
| Physical Parameters | Weight | 1100g |
| Dimension (mm) | 367×83×82 |
