| Core Optical Parameters | Resolution (Pixels) | 640×512 |
| Pixel Pitch (μm) | 12 |
| Field of View (°) | 8.8×6.6 |
| Focal Length (mm) | /50 |
| Screen Pixels | 1024×768 |
| System Magnification | 1× |
| Image Modes | White Hot / Black Hot / Green Hot / Red Hot / Iron Red |
| Physical Parameters | Weight (Without Battery, g) | 590 |
| Dimension (L × W × H, mm) | 152.5×79×72.6 |
| Laser Range Finder | Type (Wavelength, nm) | 905 |
| Maximum Ranging Distance (m) | 1200 |
| Interface & Environmental Adaptability | Standard Interface Type | RS232, USB, PAL, DC (Direct Current Power Supply) |
| Waterproof Rating (Immersion) | IP67 |
